4-Wheel 1.5-2.5 tons Electric Counterbalance Forklift 48V System
Epexlift E-MK 48V system forklift truck with a load capacity of 1.5 to 2.5 tons, equipped with full AC motor technology, high-power motors, and a high-capacity lithium ion battery to meet diverse operational demands. Battery-powered E-MK electric forklift combines stability with versatility to meet all your operational needs. The 4-wheel electric forklift truck is perfect for demanding tasks like container handling, and the electric counterbalance forklift trucks are widely used in warehousing, construction, manufacturing, and shipping ports.
- Brand : Epexlift
- Model:E-MK
- load capacity: 1500ks ,2000kgs, 2500kgs
- lifting height : from 2.5 m to 7m
About US
Epexlift is dedicated to being your most trusted partner in intelligent logistics and material handling. Guided by our core promise of “Simplifying Your Move,” we deliver reliable and efficient forklift solutions that make every material handling task both effortless and productive. Our comprehensive equipment portfolio spans Class I to Class V, offering a full selection from electric forklifts, pallet trucks, and order pickers, Very Narrow Aisle trucks,multidirection forklifts along with robust LPG and diesel models for demanding outdoor applications—ensuring we can meet virtually any operational requirement.
Contact US
Email：sales@epexlift.com
Phone：+86135 1497 1047
WhatsApp：+86135 1497 1047
Get A Quick Requests Now
HICODA will constantly satisfy worldwide customers with professional warehouse solutions, and we are ready to be your trusted partner.
Contact Us
-
Phone:+86135 1497 1047
-
E-mail: sales@epexlift.com
Description
Four Wheels Electric Counterbalance Forklifts Truck 1500-2500Kgs
Features:
-
Equipped with an advanced controller for precise handling and excellent performance
-
Full AC drive motor with maintenance-free offers reliable, energy-efficient operation
-
Pneumatic tyres for durability and smooth travel on various surfaces
-
Features include an upward limit switch, automatic descent speed control with sensing, and a descent buffer function. These ensure operational safety while preventing cargo and pallets from impacting the ground, effectively protecting both goods and surfaces.
-
The entire series incorporates a wide-view mast design that minimizes visual obstruction, providing operators with an expansive field of vision.
- New large-screen LED instrument panel displays battery charge, operating time, and fault diagnostics.
- Hydraulic system offers optional side shift and fork position adjustment functions, improving operational convenience and boosting work efficiency.
-
Available in both lead-acid and long-life lithium battery options
Details :
| 1.2 | Model | E-MK | E-MK | E-MK | ||
| 1.3 | Power type | Battery | Battery | Battery | ||
| 1.4 | Operation | Seated | Seated | Seated | ||
| 1.5 | Load capacity | Q(kg) | 1500 | 2000 | 2500 | |
| 1.6 | Load center distance | C(mm) | 500 | 500 | 500 | |
| Wheel | 3.1 | Tyre type | Pneumatic | Pneumatic | Pneumatic | |
| 3.4 | Wheels,number front/rear (X=driven) | 2X/2 | 2X/2 | 2X/2 | ||
| Dimension | 4.1 | Mast tilt angle front/rear | α/β(°) | 6/10 | 6/10 | 6/10 |
| 4.2 | Mast retracted height | h1(mm) | Refer to the mast specification | Refer to the mast specification | Refer to the mast specification | |
| 4.3 | Free Lift height | h2(mm) | 145 | 150 | 150 | |
| 4.4 | lifting height | h3(mm) | 3000 | 3000 | 3000 | |
| 4.5 | Mast extended height | h4(mm) | Refer to the mast specification | Refer to the mast specification | Refer to the mast specification | |
| 4.6 | Overhead guard height | h6(mm) | 2125 | 2150 | 2150 | |
| 4.7 | Seat index point height | h7(mm) | 1100 | 1130 | 1130 | |
| 4.8 | Towing pin height | h10(mm) | 260 | 250 | 250 | |
| 4.9 | Overall length | L1(mm) | 3297 | 3500 | 3500 | |
| 4.10 | Body to fork surface length | L2(mm) | 2227 | 2430 | 2430 | |
| 4.11 | Overall width | b1/b2(mm) | 1120 | 1160/1140 | 1160/1140 | |
| 4.12 | Fork dimensions | l/e/s(mm) | 1070/100/35 | 1070/122/40 | 1070/122/40 | |
| 4.13 | Installation level (IS02328) | 2A | 2A | 2A | ||
| 4.14 | Fork carriage width | b3(mm) | 1040 | 1040 | 1040 | |
| 4.15 | Fork outside spread | b5(mm) | 1040～200 | 1000～244 | 1000～244 | |
| 4.16 | Ground clearance below mast | m1(mm) | 100 | 120 | 120 | |
| 4.17 | Ground clearance,body | m2(mm) | 110 | 125 | 125 | |
| 4.19 | Aisle width with pallet 800*1200mm, C=600mm | mm | 3790 | 3950 | 3950 | |
| 4.21 | Turning radius | Wa(mm) | 1940 | 2100 | 2100 | |
| 6.3 | Lead-acid battery voltage/nominal capacity | V/Ah | 48/480 | 48/500 | 48/500 |
