4-Wheel 4.5-5 tons Electric Counterbalance Forklift Seated Operation
Epexlift 80V electric counterbalanced forklift truck with four wheels , have a capacity of 4.5 tons to 5 tons, featuring all the necessary components, including full AC motor technology, high-power motors, and larger batteries, which can meet the needs of various usage scenarios. The perfect ergonomic design will bring users a new driving experience. Electric are widely used for demanding indoor and outdoors material handling applications.
- Brand: Epexlift
- Model:E-MK
- load capacity: 4500kgs, 5000kgs
- lifting height:from 2.5 m to 6m
About US
Epexlift is dedicated to being your most trusted partner in intelligent logistics and material handling. Guided by our core promise of “Simplifying Your Move,” we deliver reliable and efficient forklift solutions that make every material handling task both effortless and productive. Our comprehensive equipment portfolio spans Class I to Class V, offering a full selection from electric forklifts, pallet trucks, and order pickers, Very Narrow Aisle trucks,multidirection forklifts along with robust LPG and diesel models for demanding outdoor applications—ensuring we can meet virtually any operational requirement.
Contact US
Email：sales@epexlift.com
Phone：+86135 1497 1047
WhatsApp：+86135 1497 1047
Get A Quick Requests Now
HICODA will constantly satisfy worldwide customers with professional warehouse solutions, and we are ready to be your trusted partner.
Contact Us
-
Phone:+86135 1497 1047
-
E-mail: sales@epexlift.com
Description
Four Wheels Electric Forklift Trucks Seated Operation 4500-5000Kgs
- Brand: Epexlift
- Model:E-MK
- load capacity: 4500kgs, 5000kgs
- lifting height:from 2.5 m to 6m
Epexlift offers high-capacity electric counterbalance forklift in the 4.5 to 5-ton range with a 4-wheel design. The E-MK series delivers outstanding performance, featuring a full AC drive system, robust steel side panels, and a side-mounted multi-directional valve for precise operation. With high travel speed, strong gradeability, and excellent energy efficiency, these 80V electric forklifts are widely used for demanding loading and unloading applications. Ideal for heavy-duty material handling in ports, large warehouses, logistics centers, and manufacturing facilities.
Electric counterbalanced forklifts have
| 1.2 | Model | E-MK45 | E-MK50 | |
| 1.3 | Power type | Battery | Battery | |
| 1.4 | Operation | Seated | Seated | |
| 1.5 | Load capacity | Q(kg) | 4500 | 4999 |
| 1.6 | Load center distance | C(mm) | 500 | 500 |
| 1.8 | Front overhang | x(mm) | 530 | 530 |
| 1.9 | Wheelbase | y(mm) | 2000 | 2000 |
| Wheels | ||||
| 3.1 | Tyre type,front/rear | Solid rubber | Solid rubber | |
| 3.2 | Tyre size, rear | 250-15-7.5 | 250-15-7.5 | |
| 3.3 | Tyre size, front | 21×8-9-6 | 21×8-9-6 | |
| 3.5 | Wheels,number front/rear (X=driven) | 2x/2 | 2x/2 | |
| Dimensions | ||||
| 4.1 | Mast tilt angle front/rear | α/β(°) | 6/11 | 6/11 |
| 4.2 | Mast retracted height | h1(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.3 | Free Lift height | h2(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.4 | Lift height | h3(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.5 | Mast extended height | h4(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.7 | Overhead guard height | h6(mm) | 2250 | 2250 |
| 4.8 | Seat height | h7(mm) | 1230 | 1230 |
| 4.19 | Overall length | L1(mm) | 4038 | 4038 |
| 4.20 | Body to fork surface length | L2(mm) | 2968 | 2968 |
| 4.21 | Overall width | b1/b2(mm) | 1470/1350 | 1470/1350 |
| 4.22 | Fork dimensions | l/e/s(mm) | 1070/150/50 | 1070/150/50 |
| 4.23 | Installation level | 3A | 3A | |
| 4.24 | Fork carriage width | b3(mm) | 1380 | 1380 |
| 4.25 | Fork outside spread | b5(mm) | 320~1320 | 320~1320 |
| 4.31 | Ground clearance below mast, laden | m1(mm) | 120 | 120 |
| 4.32 | Ground clearance,body | m2(mm) | 120 | 120 |
| Aisle width with pallet 800*1200mm, C=600mm | Ast(mm) | 4620 | 4620 | |
| 4.35 | Turning radius | Wa(mm) | 2690 | 2690 |
| Performance | ||||
| 5.1 | Travelling speed, laden/unladen | km/h | 12/13 | 12/13 |
| 5.2 | Lift speed, laden/unladen | mm/s | 200/220 | 200/220 |
| 5.3 | Lowering speed, laden/unladen | mm/s | 270/290 | 270/290 |
| 5.5 | Traction, laden/unladen (S2-5min) | N | 15400 | 15680 |
| 5.8 | Gradeability, laden/unladen (S2-5min) | %(tanθ ) | 14/15 | 14/15 |
| Drive | ||||
| 6.1 | Drive motor, rating S2=60 | kw | AC16.6 | AC16.6 |
| 6.2 | Lift motor, rating S3=15% | kw | AC15 | AC15 |
| 6.4 | Lead-acid battery voltage/nominal capacity (standard) | V/Ah | 80/560 | 80/630 |
